Foxygen 460Ah LiFePO4 Battery with Bluetooth & Heating FOX12V-460AH
The Foxygen 460Ah Lithium Leisure Battery is a high-performance 12V LiFePO4 battery with integrated Bluetooth monitoring, a Smart BMS and switchable heating, designed for reliable power in all conditions.
- 12-year warranty for complete peace of mind
Key Benefits
High-Quality Prismatic Cells
The battery is built with advanced prismatic cells that are certified to UL1973, UL9540, IEC62133, and IEC62619 standards. These cells deliver a cycle life of more than 3,000 cycles @100% DOD while maintaining excellent consistency and reliability over time.
Bluetooth Connectivity
An integrated Bluetooth system provides real-time monitoring of key battery parameters, including charge and discharge status, current, temperature, and cycle life. It also allows configuration adjustments for different applications, offering flexibility and enhanced control.
Intelligent Heating System
For cold-weather performance, the battery features a uniform internal heating system that ensures the cells are warmed evenly. Unlike external heating blankets, which cannot sense internal cell temperature and often heat unevenly, this proprietary system draws power directly from the charging source and requires no additional components. The process is completely seamless, simply connect the battery to any compatible lithium charger, and the built-in heating and monitoring system automatically manages both heating and charging.
High Energy Density, Lower Weight
With an energy density approximately 15% higher than conventional cells, the battery provides more power while reducing overall weight. This results in a lighter, more efficient solution without compromising performance.
Mechanical Specifications
- Dimensions: 521mm x 238mm x 218mm
- Approx Weight: 38.58Kg
- Terminal Type: M8
- Case Colour/Material: Black Plastic Case (ABS)
- IP Rating: IP65
- Cell Type: 3.2V 230Ah Prismatic Cell
- Cell Balancing: Passive
- Cell Configuration: 4S2P
Electrical Specification
- Nominal Voltage: 12.8V
- Nominal Capacity: 460Ah
- Parallel Connection: Max. 6 Units
- Serial Connection: Max 4 Units
- BMS: 4S250A
- Bluetooth: Android/iOS
- Heat: Yes (Switchable)
- Circuit Protection: Overcharge, Overdischarge, Overcurrent, Over Temp, Under Temp ShortCircuit
- Cycle Life: 6000 times @80% DOD
- Self Discharge: Less than 3% per month
- Charge Efficiency: 100% @0.2C
- Discharge Efficiency: 98-100% @1C
Charge Specification
- Charge Voltage: 14.4 ± 0.2V
- Standard Current: 92A
- Fast Current 230A
Discharge Specification
- Standard Current: 92A
- Max. Con. Current: 250A
- Cut-Off Voltage: 10V
Temperature Specification
- Charge Temp: -20°C to 55°C (-4°F to 131°F)
- Discharge Temp: -20°C to 60°C（-4°F to 140°F）
- Storage Temp: -5°C to 45°C (23°F to 113°F)
Certifications
- UL1973 (Cell)
- UL2580 (Cell)
- UL9540A (Cell)
- IEC62660 (Cell)
- IEC62619 (Cell)
- ROHS (Cell)
- CE (Cell / Pack)
- UN38.3 (Cell / Pack)
- ISO9001
- ISO45001
- ISO14001
Datasheets
